Zebra ZQ620 HC

Zebra ZQ620 HC

The ZQ620 HC takes Zebra’s popular QLn platform and makes it even better — adding advanced technology and innovative design that drive productivity, ease-of-use and manageability to a new level for Healthcare.
Get a Quote >>

Availability: Call for availability
zebra trade-in program
Product Information

Overview

The Zebra ZQ620 HC offers the fastest, most dependable wireless connections inside the four walls and your IT department will find the Zebra ZQ620 HC easier to integrate, manage and secure thanks to Zebra’s Link-OS® operating system and powerful Print DNA suite of applications, utilities and developer tools. The ZQ620 Healthcare Series — the next evolution in the gold standard for mobile specimen labeling.

PHYSICAL CHARACTERISTICS

Dimensions
6.8 in. L x 4.6 in. W x 3.3 in. H
173 mm L x 117 mm W x 84 mm H

Weight
1.6 lbs/0.73 kg

PRINTER SPECIFICATIONS

Operating SystemLink-OS®

Resolution 203 dpi/8 dots per mm

Memory256 MB RAM; 512 MB Flash (standard)

Maximum Print WidthZQ610: 1.9 in./48 mm ZQ620: 2.8 in./72 mm

Maximum Print SpeedUp to 4.5 in./115mm per second

Media Sensors Black mark and gap media sensing using fixed center position sensors; label present sensor for issuing batch labels one at a time

Print Length Minimum: 0.5 in./12.7 mm Maximum: 32 in./813 mm

Power 3250 mAh (nominal) 23.4 Wh removable, rechargeable PowerPrecision+ Li-Ion battery

MEDIA CHARACTERISTICS

Maximum Label and Liner Length
0.5 in./12.7 mm to 32 in./813 mm or continuous

Media Width
1.0 in./25 mm to 3.125 in./79 mm

Maximum Media Roll Size
2.6 in./66 mm OD on a 0.75 in./19 mm or 1.375 in./ 34.9 mm inner core

Thickness
2.3 mil to 5.5 mil tag stock or 6.5 mil label stock

Media Types
Die-cut labels and tags, linerless labels, receipt paper, black bar and gap sensing

OPERATING CHARACTERISTICS

Environment
Operating Temp.: 32°F to 122°F/ 0°C to 50°C
Operating Humidity: 10% to 90% non-condensing Storage/Transportation Temp.: -13°F to 149°F/-25°C to 65°C1
Storage Humidity: 10% to 90% non-condensing

Agency Approvals
Emissions: FCC Part 15, Subpart B, EN55022 Class-B, EN60950, EN55024 and VCCI class BSusceptibility: EN55024, EN61000-4-2, EN61000-4-3, EN61000-4-4, and EN61000-4-5Safety: CE, TUV, CSA

*Specifications are subject to change without notice
