Printronix T4000


The T4000 is our most compact and affordable industrial printer with the ability to print 5,000 labels a day at speeds of up to 8 inches per second. If you’re looking to improve productivity…look no further. The T4000 includes Printronix System Architecture (PSA), with multiple connectivity options, remote printer management tools and automated alerts to keep you enterprise operating at optimum efficiency and productivity.

Availability: In-Stock
Request A Quote >>
Talk to a Specialist
Have Questions? Talk to a live Specialist now (800) 643-2664
Product Information

Overview

The T4000 is our most compact and affordable industrial printer with the ability to print 5,000 labels a day at speeds of up to 8 inches per second. If you’re looking to improve productivity...look no further. The T4000 includes Printronix System Architecture (PSA), with multiple connectivity options, remote printer management tools and automated alerts to keep your enterprise, operating at optimum efficiency and productivity.

T4000

    High performance ARM Cortex-A7
    128MB RAM/ 128MB Flash Memory
     Printronix System Architecture (PSA)
    Color 3.5in LCD nine-key control panel
     Four-inch print width
     203 DPI or 300 DPI
    4-32 GB SD memory card capability
    Andale & Premium Asian Fonts (Option)
    Transfer and Direct Printing
    Ethernet 10/100 BaseT (Standard)
    ENERGY STAR Certified
    Steel Frame Enclosure
    Bifold Media Door
    WiFi 802.11 a/b/g/n/ac (Option)
    Bluetooth 4.2 (Option)

PRINTER CHARACTERISTICS

    Max. Print Speed 8 IPS @ 203 DPI, 6IPS @ 300 DPI
    Print Method Transfer and Direct
    Resolution 203 DPI / 300 DPI
    Max. Print Width 4.1″ (104mm

MEDIA SPECIFICATIONS

    Media Type Roll or Fan-Fold Labels, Tags, Paper, Film, Tickets Min.
    Media Width 1.0” (25.4mm)
    Max. Media Width 4.72” (120mm)
    Min. Media Length Continuous 0.25”, Tear-Off / Peel-Off 1.0”
    Max. Media Length Up to 50”
    Media Thickness 0.00236” (0.06mm) to 0.011” (0.279mm)
    Media Roll Core Diameter 3.0″ (76.2mm)
    Max. Media Roll Diameter 8.0″ (203mm)
    Media Sensing Gap, Mark

RIBBON CHARACTERISTICS

    Ribbon Type Wax, Wax/Resin, Resin
    Min. Ribbon Width 1.6″ (40mm)
    Max. Ribbon Width 4.33″ (110mm)
    Max. Ribbon Length 450 Meters
    Ribbon Core Diameter 1.0in

PHYSICAL CHARACTERISTICS

    Width 10.4″ (264mm)
    Height 10.9″ (276mm)
    Depth 17.9″ (455mm)
    Printer Weight 22 lbs (10Kg)
    Shipping Weight 28 lbs (13Kg)

PRINTER LANGUAGE

    Printer Languages: (Native / Competitor) PGL/ZGL/TGL/IGL/STGL/DGL/IEGL/MGL/EGL
    API’s: XML
    Legacy Line Printer Emulations: VGL (Code V), P-Series / XQ, Epson FX,Serial Matrix, Proprinter
    Job Control Languages: PJL, PTX-SETUP

COMMUNICATION & CONNECTIVITY/INTERFACE

    Standard Interface I/O: Serial RS232, USB Device (Type B), USB Host (Type A) and Ethernet 10/100Base T
    Optional Interface I/O: WiFi (802.11a/b/g/n/ac), (WiFi Alliance Certified) Bluetooth 4.2
    WiFi Security Protocol: WEP 40/128bit, TKIP, AES CCMP
    WiFi Security Authentication: WPA/WPA2 PSK, EAP-TTLS, EAP-PEAP, LEAP, PEAPv1/PEAP-TLS, PEAPv0/MS-CHAPv2

MEDIA HANDLING MODES

    Standard: Continuous, Tear-Off
    Options: Peel/Rewind (paper labels, 6ips, rewinds liner from 8in roll) Cutter (thickness as per media spec, life 500,000 cuts)

OPERATING ENVIRONMENT

    Operating Temperature: 32 to 104°F (0 to 40°C)
    Operating Humidity: 25 – 85% Non-Condensing
    Storage Temperature: -40 to 140°F (-40 to +60°C)
    Storage Humidity: 10 – 90% Non-Condensing

POWER REQUIREMENT

    Auto Range 100 – 240 VAC (48 – 62 Hz)

REGULATORY COMPLIANCE

    Emissions: FCC, CE, IC, CCC, KC
    Safety: cTUVus, CE, IC, EAC, S-MARK, NOM, CCC, KC, BIS, BSMI
    Environmental: RoHS, WEEE, Energy Star
    WiFi / BT: FFC, IC, CE, CCC
    Energy Savings: Energy Star 2.0

BAR CODE SYMBOLOGIES

    1D Barcodes: BC-412, Code 11, Code 39, Code35, Code 93, Codabar, Code 128 Subsets A/B/C, Industrial 2 of 5, Interleave 2 of 5, German 1-2/5, EAN-8, EAN-13, UCC/EAN-128, UPC-A, UPC-E, UPCSHIP, UPS 11, MSI, Matrix 2 of 5, PLESSEY, POSTNET, 4-state PostBar, Austrailian 4-state, FIM, ITF14, TELEPEN, PLANET, USPS Intelligent Mail, LOGMARS
    2D Barcodes: PDF-417, MicroPDF-417, Maxicode, DataMatrix, QR Codes, Aztec, GS1 Databar (RSS-14)

FONT, GRAPHIC SUPPORT

    Graphic Formats: PCX, TIFF, BMP, PNG
    Font Technologies: Intellifont, TrueType, Unicode
    Standard Fonts: OCRA, OCRB, Courier, Letter Gothic, CG Times, CG Triumvirate/Bold/Condensed
    Asian Fonts (Optional SD card): Simplified Chinese, Japanese, and Korean

REMOTE MANAGEMENT SOFTWARE

    PrintNet Enterprise Auto ID: Enterprise Grade Remote Management Solution

OPTIONS AND ACCESSORIES

    WiFi 802.11 a/b/g/n/ac
    Bluetooth 4.2 *
    Cutter
    Peel/Rewind
    Andale Asian Font Cards (SD Card)
    Premium Asian Font Cards (SD Card)
    QCMC (Quick Change Memory Card) (SD-Card)


*Specifications are subject to change without notice
